Compact Digital Mixer for Professional Audio Control

The Yamaha TF-Rack is a versatile, compact digital mixing solution that offers the renowned performance of the TF Series in a rack-mountable form. Perfect for live sound reinforcement, corporate events, and installations, this mixer combines intuitive touch panel control with advanced sound processing features, ensuring high-quality audio in any environment. Its space-saving design makes it ideal for limited setups, while its user-friendly interface allows for smooth operation by both beginners and experienced engineers.

Yamaha TF-Rack Competitive Differences

TouchFlow Operation™ optimized for touch panel control
Recallable D-PRE™ microphone preamplifiers for superior sound quality
1-knob COMP™ and 1-knob EQ™ for simplified audio adjustments
Scene memory with up to 200 pre-programmed or customized scenes
QuickPro Presets™ designed in collaboration with top audio engineers
Expandable I/O capability with up to 64 inputs and 40 outputs via Dante Stagebox
Compact, rack-mount design perfect for space-constrained environments

Yamaha TF-Rack Description

The Yamaha TF-Rack is a compact, all-in-one digital mixer that brings the power of the TF Series to a rack-mount form factor. Designed with Yamaha’s groundbreaking TouchFlow Operation™, it enables intuitive touch control, making it easy for users of all experience levels to achieve optimal sound mixes. Whether used for live sound reinforcement, installations, or corporate events, the TF-Rack offers professional-level audio performance with an emphasis on ease of use. With 16 mic/line inputs, 1 stereo line input, and 16 outputs, the TF-Rack is equipped to handle a variety of applications. It features Yamaha’s D-PRE™ microphone preamplifiers, known for their pristine sound quality, and offers scene memory that can store up to 200 scenes for instant recall. The inclusion of the 1-knob COMP™ and 1-knob EQ™ provides fast and easy audio adjustments, while the expandable I/O options make it a flexible choice for larger setups. Yamaha has also included QuickPro Presets™, developed in collaboration with industry professionals, allowing even novice users to achieve professional-level sound quickly. The TF-Rack can be expanded with optional Tio1608-D I/O racks, offering a total of 64 inputs and 40 outputs when fully configured, making it suitable for larger productions.

TF-Rack Features

TouchFlow Operation™ with touch panel for intuitive control
Scene memory: Stores up to 200 scenes for instant recall
1-knob COMP™ and 1-knob EQ™ for simplified sound adjustments
16 mic/line inputs (XLR/TRS combo) + 1 stereo line input (RCA)
16 outputs (8 XLR + 8 TRS)
Expandable I/O via optional NY64-D Dante card (up to 64 inputs/40 outputs)
QuickPro Presets™ for professional-grade microphone and output settings
Recallable D-PRE™ microphone preamplifiers for natural, clear sound
8 onboard effects processors (reverb, delay, modulation, multiband compression)
Wireless control through TF StageMix™ for iPad and MonitorMix for personal AUX mixing

TF-Rack Specifications

Mixing capacity: 40 input channels (32 mono, 2 stereo, 2 return)
Aux buses: 20 (8 mono, 6 stereo)
Stereo buses: 1
Sub buses: 1
Input channels: 16 mic/line (XLR/TRS combo) + 1 stereo line (RCA)
Outputs: 16 (8 XLR + 8 TRS)
Expansion slot: 1 (for NY64-D Dante card)
Onboard processors: 8 effects + 10 GEQ
Sampling rate: 48 kHz
Signal delay: Less than 2.6 ms (INPUT to OMNI OUT, 48 kHz)
Fader resolution: 10-bit, +10 dB to –138 dB, –∞ dB all faders
Total harmonic distortion: Less than 0.05%, 20 Hz–20 kHz
Frequency response: +0.5, –1.5 dB (20 Hz–20 kHz)
Dynamic range: 110 dB (DA converter), 108 dB (input to OMNI OUT)
Hum & noise level: –128 dBu (equivalent input noise, max gain)
Residual output noise: –85 dBu (ST master off)
Crosstalk: –100 dB (adjacent INPUT/OMNI OUT channels)
Power requirements: 100–240 V, 50/60 Hz
Power consumption: 85W
Dimensions (W x H x D): 18-7/8 in x 5-1/4 in x 16-1/8 in (480 mm x 132 mm x 409 mm)
Net weight: 20.3 lbs (9.2 kg)

What's In The Box

Yamaha TF-Rack digital mixer
Power cord
Quick Guide
Rubber stoppers (4)
NUENDO Live DAW software

TF-Rack Manual
