Shure RPW120 | Beta 87A Supercardioid Condenser Capsule for Handheld Transmitter

The RPW120 from Shure is a Beta 87A condenser microphone capsule compatible with most interchangeable Shure handheld transmitters (available separately), with the exception of the BLX and GLX-D systems. It delivers a clear, detailed vocal sound for professional sound reinforcement, broadcasting, and studio recording applications.

The uniform supercardioid polar pattern provides maximized gain-before-feedback along with a smooth frequency response and high sound pressure level capability (140.5 dB).

Featuring an electronic low-frequency roll-off and a shockmount system, the capsule virtually eliminates proximity effect and reduces handling noise. Its circuitry is designed for low susceptibility to RFI and electromagnetic hum.

FEATURES:

Compatible with all Shure handheld transmitters except BLX and GLX-D systems
Smooth frequency response with gradual presence rise
Highly-consistent supercardioid polar pattern provides maximized gain-before-feedback
Electronic low-frequency roll-off compensates for proximity effect
Wide dynamic range (117 dB) and low-distortion characteristics
Low susceptibility to RFI and electromagnetic hum
Advanced cartridge shockmount system absorbs mechanical shocks and reduces handling noise
Built-in pop filter reduces undesirable wind and breath sounds

SPECIFICATIONS:

Compatible Transmitters
Shure: Axient, PG, PGX, QLXD, SLX, UHF-R, ULX, ULXD, UR2
Element Type
Electret Condenser
Polar Pattern
Supercardioid
Performance
Frequency Range
20 Hz to 20 kHz
Maximum SPL
140.5 dB SPL
Sensitivity
-52.5 dBV/Pa
2 mV
Dynamic Range
117 dB
Signal-to-Noise Ratio
70.5 dB
Connectivity
Output Connector
1x Concentric Ring 3-Pin
Physical
Mounting Thread Size
1.25"-28 Male
Packaging Info
Package Weight
0.5 lb
Box Dimensions (LxWxH)
4.7 x 3.4 x 3.3"
