Obsidian Netron NS8 | 8-Port Gigabit Network Switch with PoE+ Support

Compact Gigabit Network Switch with PoE+ for Entertainment Applications

The NETRON NS8 is a highly efficient and compact 8-port Gigabit network switch, designed to meet the demands of modern entertainment systems. With PoE+ support and a 100W power budget, the NS8 delivers seamless data distribution and power management for NETRON nodes or any PoE-compatible devices. Its robust design and flexible mounting options make it ideal for both live productions and permanent installations.

NETRON NS8 Competitive Differences

• 8 Gigabit Ethernet ports optimized for high-data entertainment protocols.
• Supports Artnet, sACN, X-Net, HogNet, MA-Net, and ETC Net3.
• 100W PoE+ total power budget with individual port power management.
• Factory and user-configurable presets for effortless setup.
• Convection-cooled, rugged powder-coated aluminum housing.
• Flexible mounting options: rack, truss, wall, and DIN rail.
• Remote configuration via internal webpage for easy control.

NETRON NS8 Description

The NETRON NS8 is engineered to handle the high data demands of today's lighting and entertainment systems. It distributes multiple protocols, including Artnet, sACN, MA-Net, and more, with zero delay for flawless operation. Its rugged design and compact size fit perfectly in dynamic environments, while the convection-cooled housing ensures reliable operation even under intensive use. The NS8's PoE+ capabilities enable it to power compatible devices efficiently, reducing cabling clutter. Mounting flexibility allows the NS8 to adapt to any setup, whether it’s a standalone installation, truss-mounted, or integrated into a rack or wall configuration. With advanced features like VLAN group management, IGMP Snooping, and QoS presets, the NS8 ensures optimized performance for Dante, multicast, and unicast traffic.

NS8 Features

• 8 Gigabit Ethernet ports with locking RJ45 connectors.
• PoE (15W) and PoE+ (30W) support with a 100W total power budget.
• IGMP Querier and Snooping for multicast optimization.
• VLAN with six groups, trunking, and color coding for organization.
• Dante-compliant QoS presets for enhanced audio performance.
• Internal webpage for remote configuration and monitoring.
• LED feedback for activity, link, PoE, and VLAN status.
• Convection-cooled, powder-coated aluminum housing.

NS8 Specifications

• Front Connections: 6 locking RJ45 Ethernet ports with LED feedback.
• Back Connections: 2 locking RJ45 Ethernet ports, locking power in/thru.
• Supported Protocols: sACN, Artnet, Dante, MANet2, MA-Net3, HogNet, ETC Net3.
• Network Standards: IEEE 802.3, 802.3ab, 802.3x, 802.1p, 802.3at, 802.3af, 802.1Q, IGMPv2/v3.
• Total Switching Capacity: 10 Gbps.
• Power: 100–240V AC, 50/60Hz, 109W maximum.
• Dimensions: 5.8 in. (147 mm) L x 8.5 in. (215 mm) W x 1.65 in. (42 mm) H.
• Weight: 2.4 lbs. (1.1 kg).
• Approvals: cETLus, CE, IP20, FCC.

What's In The Box

• 1.5m locking IP65 power cable (EU or US version).
• (2) Wall-mount plates.
• (2) DIN-rail clamps.
