Magmatic Prisma Driver 8

$607.00

Order within [hour] to get by [date_end]

Quantity

Call For More Details

Call us at 123-456-7890

Guarantee Safe
Checkout

trust_2dea69ed-7223-44f3-828d-a80bc0f3aef4

PRISMA DRIVER 8™ is an easy to use 48VDC driver system which provides individual DMX-512 control including variable delayed time dimming modes for up to (8) PRISMA MINI UV LED series fixtures including the PRISMA MINI PAR 20™, PRISMA MINI PAR 45™, and the PRISMA MINI BAR 20™.

Features include a rugged aluminum housing, easy keyhole slots for wall and surface mounting, multiple DMX control modes, an onboard 4 button touch control panel, 8x 2pin bare wire terminal blocks, DMX 5pin locking XLR in/out, and locking power in/out.

Features:
48VDC Power Driver for up to 8 PRISMA MINI UV LED Fixtures
2pin Bare Wire Block Terminal Connections (x8)
DMX-512 and Manual Control

Specifications:
CONSTRUCTION
Rugged Aluminum Housing
Easy Keyhole Slots for Wall/Surface Mounting

CONTROL
Multiple DMX Channel Modes
Onboard 4 Button Touch Control Panel
DMX-512 and RDM Protocol Support

CONNECTIONS
8x 2pin Bare Wire Block Terminals (8 PRISMA MINI fixtures max)
Locking 5pin XLR Connector In/Out
IP65 Locking Power Connector In/Out
With Wired Digital Communication Network

SIZE / WEIGHT
Length: 8.9 in. (226mm)
Width: 7.4 in. (188mm)
Vertical Height: 3.2 in. (81mm)
Weight: 5.7 lbs. (2.6 kg)

ELECTRICAL
AC100-240V 50-60Hz
48VDC 8.3A
167W Max Power Consumption

THERMAL
Ambient Temperature (Ta max) 104°F (40°C)

APPROVALS / RATINGS
CE | cETLus | IP20
