Mackie 802VLZ4 8-Channel Ultra-Compact Mixer | Professional Audio Performance

High-Performance 8-Channel Mixer with Onyx Preamps

The Mackie 802VLZ4 is an ultra-compact 8-channel mixer, featuring Mackie's renowned high-headroom/low-noise design and Onyx mic preamps for professional sound quality. With rugged construction and versatile features, this mixer is perfect for both live and studio applications.

Competitive Differences

• 3 boutique-quality Onyx mic preamps offer ultra-wide 60 dB gain range and low distortion.
• 3-band EQ and 100 Hz low-cut filter for precise sound shaping.
• ALT 3/4 stereo bus provides added routing flexibility for advanced mixing setups.
• Built-Like-A-Tank chassis with a powder-coat finish ensures durability for demanding environments.

Full Description

The Mackie 802VLZ4 mixer brings professional sound performance to any audio setup. Featuring 3 boutique-quality Onyx mic preamps , it delivers high-headroom, low-noise audio with a wide gain range of 60 dB. The mixer is optimized for any input/output configuration, with improved RF rejection for broadcast applications and phantom power for condenser microphones. Each channel includes aux send, level, pan, and PFL solo controls, and the ALT 3/4 stereo bus provides flexible routing options. The sealed rotary controls are designed to resist dust and grime, ensuring longevity. Perfect for both small live sound applications and studio recording, the 802VLZ4 provides a reliable, high-quality audio solution.

Features

• 8-channel mixer featuring Mackie's signature high-headroom/low-noise design
• 3 boutique-quality Onyx mic preamps with wide 60 dB gain range and 128.5 dB dynamic range
• Low distortion: under 0.0007% (20 Hz – 50 kHz)
• Improved RF rejection for broadcast applications
• Phantom power for condenser microphones
• 3-band EQ (80 Hz, 2.5 kHz, 12 kHz)
• 100 Hz low-cut filter on mic input channels
• AUX send, level, pan, and PFL solo on each channel
• ALT 3/4 stereo bus for added routing flexibility
• Stereo return for connecting external FX processors
• High-resolution 12-segment stereo meters
• Built-Like-A-Tank rugged steel chassis with powder-coat finish
• High-visibility, high-contrast controls for convenient at-a-glance feedback

Specifications

• Noise (Main Mix, XLR output): -95 dBu
• Signal-to-Noise Ratio: 102 dB
• THD: <0.001% (Mic pre @ insert, 1 kHz, 30 dB gain)
• Frequency Response: +0, -1 dB (20 Hz to 50 kHz)
• Maximum Input Levels: Mic In: +21 dBu , Tape In: +22 dBu
• Maximum Output Levels: Main Mix XLR Out: +28 dBu
• Equalizer: High Shelving: ±15 dB at 12 kHz , Mid Peaking: ±15 dB at 2.5 kHz , Low Shelving: ±15 dB at 80 Hz
• Impedance: Mic In: 2.55 kΩ , Instrument In: 1 MΩ , All Other Inputs: 10 kΩ or greater
• Power Consumption: 8 W , Universal Power Supply
• Dimensions: 10.7 x 8.9 x 1.8 inches (271 x 226 x 46 mm)
• Weight: 5.5 lbs (2.5 kg) with power supply

What's in the Box

• Mackie 802VLZ4 Mixer
• External Power Supply
• Owner’s Manual
