Mackie 1642VLZ4

Mackie 1642VLZ4 16-Channel 4-Bus Compact Mixer | Professional Sound and Flexibility

16-Channel Mixer with Onyx Preamps and Built-Like-A-Tank Construction

The Mackie 1642VLZ4 is a 16-channel 4-bus compact mixer that delivers premium sound quality with its 10 boutique-quality Onyx microphone preamps and high-headroom, low-noise design . Designed for bands, clubs, and professional audio setups, this mixer ensures exceptional performance from input to output. Built tough with a solid-steel chassis , it’s the ideal choice for demanding environments.

Competitive Differences

• 10 Onyx mic preamps offer an ultra-wide 60 dB gain range and superior sound quality.
• 4 aux sends per channel for flexible routing and external effects integration.
• ALT 3/4 stereo bus provides additional routing flexibility.
• Sealed rotary controls resist dust and grime, ensuring long-lasting performance.
• Rugged Built-Like-A-Tank construction with high-contrast controls for intuitive operation.

Full Description

The Mackie 1642VLZ4 16-Channel 4-Bus Mixer combines Mackie’s signature high-headroom/low-noise design with the versatility and ruggedness needed for professional applications. Featuring 10 Onyx mic preamps and 16 high-headroom line inputs , this mixer is designed to provide pristine audio quality in any situation. Its compact design is complemented by 4 aux sends , 60mm log-taper faders , and an ALT 3/4 stereo bus for flexible routing options. The 1642VLZ4 is built to withstand the rigors of live sound environments, featuring a solid-steel chassis with sealed rotary controls that resist dust and grime. The high-contrast controls and high-resolution 12-segment stereo meters make it easy to operate, even in challenging settings. Ideal for live performances, studio work, and broadcast applications, the Mackie 1642VLZ4 delivers the best in professional sound mixing.

Features

• 16-channel mixer with Mackie’s high-headroom, low-noise design
• 10 Onyx mic preamps with ultra-wide 60 dB gain range and 128.5 dB dynamic range
• Low distortion: <0.0007% (20 Hz – 50 kHz)
• Phantom power for condenser microphones
• 16 high-headroom line inputs with +4/-10 operation control
• 4 aux sends, level, pan, and PFL solo on each channel
• 3-band EQ (80 Hz, 2.5 kHz, 12 kHz) with 18 dB/oct 75 Hz low-cut filter
• 60mm log-taper faders for smooth, precise control
• ALT 3/4 stereo bus for flexible routing options
• Control room/phones source matrix for easy monitoring
• High-resolution 12-segment stereo meters
• Sealed rotary controls resist dust and grime
• Rugged steel chassis with powder-coat finish for durability
• Rack-mountable design with optional rack ear kit
• Multi-voltage power supply for worldwide use

Specifications

• Noise (Main Mix Fader at Unity, Channel Faders Down): -86.5 dBu
• Total Harmonic Distortion (THD): <0.0007% (Mic In to Insert Send)
• Crosstalk/Attenuation (Channel Mute Switch Engaged): -82 dBu
• Equivalent Input Noise (EIN): -128.5 dBu (150 Ω Termination, 20 Hz – 20 kHz)
• Frequency Response: +0, -1 dB (20 Hz to 50 kHz)
• Maximum Input Levels: Mic In: +22 dBu , All Other Inputs: +22 dBu
• Maximum Output Levels: Main Mix TRS/XLR Out: +28 dBu , All Other Outputs: +22 dBu
• Power Consumption: 50 W , Multi-voltage power supply
• Dimensions: 5.2 x 16.6 x 16.7 inches (HxWxD)
• Weight: 18.2 lbs (8.3 kg)

What's in the Box

• Mackie 1642VLZ4 Mixer
• External Power Supply
• Owner’s Manual
