Mackie 1402VLZ4 | Ins: 6 Mic, 4 Line - FX

Mackie 1402VLZ4 14-Channel Compact Mixer | Professional-Grade Audio Solution

Versatile 14-Channel Mixer with Onyx Preamps

The Mackie 1402VLZ4 is a professional 14-channel compact mixer that delivers superior sound quality with its high-headroom/low-noise design and Onyx microphone preamps . With flexible I/O options and a rugged solid-steel chassis , the 1402VLZ4 is ideal for live sound, studio recording, and broadcast applications.

Competitive Differences

• 6 boutique-quality Onyx mic preamps provide ultra-low noise and wide 60 dB gain range.
• 60mm log-taper faders deliver precise control for professional mixing.
• ALT 3/4 stereo bus offers added routing flexibility for complex audio setups.
• Durable, built-like-a-tank steel chassis ensures long-term reliability.
• Sealed rotary controls resist dust and grime, ensuring a long life of smooth operation.

Full Description

The Mackie 1402VLZ4 14-Channel Compact Mixer offers exceptional audio performance with 6 premium Onyx microphone preamps and a high-headroom, low-noise design. Built to withstand the rigors of live performances and studio environments, the 1402VLZ4 is perfect for a variety of professional audio applications. The mixer features 60mm log-taper faders for smooth, accurate control and a dedicated control room section for flexible monitoring options. With two AUX sends per channel, high-resolution 12-segment stereo meters, and a rugged steel chassis, the 1402VLZ4 ensures you can achieve professional results every time. The ALT 3/4 stereo bus allows for advanced routing, and the sealed rotary controls keep out dust and debris, making it reliable for long-term use.

Features

• 14-channel mixer with high-headroom/low-noise design
• 6 Onyx mic preamps with 60 dB gain range and 128.5 dB dynamic range
• Ultra-low distortion: <0.0007% (20 Hz – 50 kHz)
• Phantom power for condenser microphones
• 3-band EQ (80 Hz, 2.5 kHz, 12 kHz) with 18 dB/octave 75 Hz low-cut filter
• Two AUX sends per channel and ALT 3/4 stereo bus for routing flexibility
• 60mm long-wearing log-taper faders for smooth control
• High-resolution 12-segment stereo meters
• Sealed rotary controls resist dust and grime for long-term reliability
• Rugged steel chassis with powder-coat finish
• Rackmountable with optional rack ear kit
• Multi-voltage power supply for worldwide use

Specifications

• Noise (Main Mix Fader Down, Channel Faders Down): -101 dBu
• Total Harmonic Distortion (THD): <0.0007% (Microphone Pre @ Insert)
• Crosstalk/Attenuation (Main Mix Fader Down): -100 dBu
• Frequency Response: +0, -1 dB (20 Hz to 50 kHz)
• Maximum Input Levels: Microphone In: +22 dBu , Tape In: +16 dBu
• Maximum Output Levels: Main Mix XLR Out: +28 dBu
• Impedance: Microphone In: 2.5 kΩ , Channel Insert Return: 2.5 kΩ
• Power Consumption: 25 W , Multi-voltage power supply
• Dimensions: 12.5 x 14.0 x 3.2 inches (317 x 356 x 81 mm)
• Weight: 9.5 lbs (4.5 kg)

What's in the Box

• Mackie 1402VLZ4 Mixer
• External Power Supply
• Owner’s Manual
