LD Systems CURV 500 SLAW

CURV 500 SLA W
SmartLink Adapter for up to Four LD CURV 500® Satellites, White
Item No.: LDCURV500SLAW

Features:

Base for LD CURV 500® system
2 x 16 mm flange for an optimised dispersion angle
4 x M6 threads for wall mounting
4 x M3 threads for ceiling mounting
4 rubber feet for non-slip positioning
Speakon-compatible connection for usual speaker cables
Rotating logo for ceiling mounting
Terminal block

The innovative SmartLink® Adapter is the perfect base for the CURV 500® system. With the patented click mechanism, up to 6 satellites can be connected with each other, without the need for any cables. Two 16 mm flanges allow for different angles on the stand. So, depending on the assembly option, an optimised sound is possible. Four M6 threads for wall mounting, four M3 threads for the ceiling and four rubber feet provide a wide range of possibilities. Thanks to the Speakon-compatible socket and the terminal block, two input variants are available. In case of ceiling mounting, the LD Systems logo simply rotates. The powder-coated cabinet made of die-cast aluminium, with dimensions of 122 x 57 x 122 mm, weighs 0.54 kg.

Specifications:

Product type PA Complete Systems Accessories
Type Smartlink® Adapter
Material die-cast aluminium
Surface Powder coated
Connectors 1x Phoenix , 1x Speakon compatible
Colour white
Width 122 mm
Height 122 mm
Depth 57 mm
Weight 0,35 kg
Features 2 x 16 mm flanges , 2x M6 thread for optional wall mount
