JTS CS-W4T | Wireless Desktop Transmitter for CS-W4C Conference System

Wireless desktop microphone transmitter for conference systems

The JTS CS-W4T is a wireless desktop microphone transmitter designed for seamless integration with the CS-W4C wireless conference receiver. Ideal for professional conferencing applications, it offers reliable transmission, logic control capabilities, and priority settings to streamline structured discussions. With support for REMOSET and dual power options, the CS-W4T is a flexible and efficient solution for modern conference environments.

JTS CS-W4T Competitive Differences

• Compatible with the JTS CS-W4C wireless conference receiver
• Supports logic-based priority override for chairman microphones
• REMOSET-enabled for fast and easy pairing via 2.4 GHz
• Operates within the 502–694 MHz T-band frequency range
• Dual RF output levels (Low / High) for flexible transmission settings
• Powered by 2 x AA batteries with rechargeable capability
• Compact desktop design ideal for conference tables and podiums

JTS CS-W4T Description

The JTS CS-W4T serves as the transmitter unit in the JTS CS-W4C wireless conference system. Designed in a desktop microphone form factor, it brings both aesthetics and functionality to professional meetings. With support for priority logic, the CS-W4T can be designated as a chairman microphone, overriding other active mics in the system. This ensures clear leadership in structured conversations or moderated discussions.

Pairing is simple and efficient thanks to the JTS patented REMOSET technology, which allows all transmitters to be synced via a single button on the receiver. Operating within a wide frequency range of 502–694 MHz (T band) and offering selectable RF output levels, the CS-W4T ensures stable and interference-resistant performance across varying venue sizes.

The unit is powered by two AA batteries and includes support for rechargeable options, making it both convenient and environmentally friendly. A compact form factor makes it perfect for use on desks, lecterns, or shared conference tables, providing a clean and professional appearance while maintaining robust functionality.

CS-W4T Features

• Wireless desktop transmitter for use with CS-W4C receiver
• Logic-compatible for chairman priority override functionality
• REMOSET technology enables quick ID pairing via 2.4 GHz RF
• Supports dual RF output levels (Low / High)
• LCD display with easy-access control functions
• Compact base for unobtrusive desktop placement
• Powered by 2 x AA batteries (rechargeable supported)

CS-W4T Specifications

• Frequency Control: PLL Synthesized
• Carrier Frequency Range: 470–960 MHz
• Operating Band: 502.000–694.000 MHz (T band)
• Frequency Setting: 2.4 GHz RF REMOSET
• RF Output Power: Low / High
• Frequency Stability: <±10 kHz @ Fc
• Frequency Deviation: ±48 kHz
• Spurious Emissions: <-50 dBc
• Display: LCD
• Controls: Power ON/OFF, Talk, Group, Channel, Frequency, Sensitivity, RF Output, Key Lock, REMOSET ID Pairing, REMOSET Setting
• Battery Type: 2 x AA (UM3)
• Rechargeable Support: Yes
• Dimensions: 4.6" (W) x 1.1" (H) x 5.4" (D) [116 x 29 x 138 mm]
