ELECTRO PANEL W18

FEATURES:

216W (18 x 12W) RGB+L LEDs
11-Hour Battery with Battery Saving Options
Lumen Radio (CRMX) Wireless DMX and RDM
Built-In Preset Colors with Auto programs
IP65 Rating with Included Barn Doors and Optional Beam Angle Diffusers

SPECIFICATIONS:

Light Source
18 x 12W RGBL LEDs
LED Life Expectancy: 50,000 hrs

Color System
RGBL Color Mixing 32 bit
Color Temperature Range: 2,500K -5,600k
Fading/Jumping Macros

Body
Die-Cast Aluminum and Steel Structure
Exterior Finish: Black

Electronics
Linear LED Dimmer: 0-100% Smooth
Linear CTO: We NEED
Strobe Shutter: 0-25H
Dimming Modes: 4 Different Ones

Electrical
Input Voltage: 100 V – 260 V AC, 50 -60 Hz
Power Consumption: 216W
Included 45ft Range, IR Remote
PWM: 1.5KHz
Power Linking for connecting fixture in daisy-chain
Up to 8 units @110V with a 20A circuit
Up to 14 units @208V with a 20A circuit
Up to 17 units @230V with a 20A circuit
Battery Voltage: 25.9V,
Battery Capacity: 12,5000 mAh, 323.8 Wh/hour
Charger: 36V, 5.5A
Battery Type: Lithium Ion
Rechargeable: Yes
Run Time: Full On: 3 hr 40 min, Single: 11 hours
Charging Time: 2.5 hrs
Battery Life Selectable: 50%, 60%, 70%, 80%, 90%, 100%

Optics
Install Optic: 20 Degree
Filter 1 Beam Angle: 40 Degree
Filter 2 Beam Angle: 60 x 10 Degree
Filter 3 Beam Angle: 80 Degree

Dynamic Effect
Tilt Range: 0-360 Degree
64 Preset Color Macros
Stand Alone Color Mixing: Yes
Dimmer: Electronic
Shutter/Strobe: Electronic
Strobe Rate: 0-25 Hz
Dim Mode: 4
Built-In Automated Programs: Yes
Emergency Mode: Same W8

Control
Control Protocol: DMX, RDM
Wireless DMX: Lumen Radio (CRMX) with RDM
Personalities: 3/4/6/8/11 CH DMX Modes
Setting and addressing: OLED Graphical Display, RDM ANSI E2.20, Standalone Mode

Physical
IP Rating: 65
Cooling: Fanless
Power Connection: US Edison (UL Listed) plug to Seetronic Powercon IP65 True1
Power Input: Seetronic Powercon IP65 True1
Power Output: Seetronic Powercon IP65 True1
Data Connectors: Seetronic 5pin XLR
Cable Length: Power 5 feet (1.5 meter); DMX 5 feet (1.5 meter)
Dimensions: 16.2” x 7.3” x 10.6”
Weight: 23.2 lbs
Certification / Qualifications

RoHS, CE, FCC
IP Rating: IP 65
Operating Temperature: 40 ° C ( 104 °F)
Minimum Temperature: – 10 ° C ( 14 ° F)
Maximum Temperature: 60 ° C ( 140 ° F)

Box Content
1 x Electro Panel W18
1 x Powercon IP65 TRUE1 Power cable
1 x 5 pin DMX Cable
1 x User Manual
1 x Omega Brackets
1 x Safety Cable
1 x IR Remote
