Osiris 3.9 Outdoor LED Video Wall (500×1000) | 3.9 mm Pixel Pitch – 4,500 nits - IP65

Outdoor LED Video Wall Panel

BrightBox Osiris 3.9 Outdoor LED Video Wall (500×1000) is a purpose‑built large‑format LED panel module designed for outdoor use, high‑visibility signage and pro‑AV installations. With its 500 × 1000 mm size, 3.9 mm pixel pitch and 4,500 nits brightness, it gives installers the flexibility to build big screens that remain visible even in bright daylight.

BrightBox Osiris 3.9 Competitive Differences

• 500 × 1000 mm panel size – larger footprint for faster build‑out
• 3.9 mm pixel pitch with 4,500 nits brightness – optimized for outdoor daylight visibility
• Weather‑rated IP65 front / IP54 rear – rugged for outdoor use
• Curvature capability ±5° – supports slightly curved installations
• Front and rear serviceability; swappable all‑in‑one power box – ease of maintenance

BrightBox Osiris 3.9 Description

The BrightBox Osiris 3.9 Outdoor LED Video Wall Panel offers a pro‑grade solution for outdoor video walls where performance and durability matter. The robust 500 × 1000 mm aluminium cabinet brings a substantial size that reduces the number of modules required to fill large areas, simplifying rigging and alignment. Its 3.9 mm pixel pitch keeps image quality sharp at moderate viewing distances, while the ultra‑bright 4,500 nits rating ensures visibility even in direct sunlight.

Weatherproofing is baked in: the front is rated IP65 and the rear IP54, allowing for outdoor installations where exposure to dust and moisture is expected. The module supports curvature of plus/minus 5°, enabling slightly convex or concave walls for immersive visual experiences.

Maintenance is simplified thanks to front and back servicing options, making this panel user‑friendly in both fixed and rental/travel‑case scenarios. A swappable power box and integrated corner protection enhance on‑site durability. Whether for outdoor corporate installations, arena stage backdrops, live event walls or LED billboards, the Osiris 3.9 outdoor format delivers the scale, brightness and serviceability professionals require.

Model Features

• 3.9 mm pixel pitch
• 4,500 nits brightness – daylight capable
• IP65 front / IP54 rear weather rating
• 500 × 1000 × 83 mm cabinet dimensions (approx 19.6" × 39.3" × 3.2") – 30.8 lbs (≈14 kg)
• Panel resolution per module: 128 × 256 pixels
• LED type: SMD1921
• Refresh rate ≥ 3,840 Hz – flicker‑free for broadcast/live event use
• Curvature support: ±5°
• Front + rear serviceable, swappable all‑in‑one power module, corner protection built‑in

Model Specifications

• Pixel Pitch: 3.9 mm
• Panel Dimensions: 500 × 1000 × 83 mm (19.6" × 39.3" × 3.2")
• Weight: approx 30.8 lb (≈14 kg)
• Brightness: 4,500 nits
• Pixel Resolution: 128 × 256 pixels per module
• LED Type: SMD1921
• Refresh Rate: ≥ 3,840 Hz
• IP Rating: Front IP65 / Rear IP54
• Curvature: ±5°
• Certifications: ETL / FCC / RoHS / CE

What's In The Box

• Main LED panel module (500 × 1000 mm)
• Swappable power module installed
• Road case packaging (ships in road case)
