JMaz Aero Wash 710Z (battery)

AERO WASH 710Z
The JMAZ AERO WASH 710Z is a break through battery moving head which can still hold events without any cables. It is a battery-driven with an impressive 7-9 hours operation in typical use. Receiving signal with internal wireless dmx receiver. It features a smooth, fast and quiet motorized zoom from 6°-60°range. It also features 7x 15W 4-in-1 RGBW LEDs, The JMAZ AERO WASH 710Z is flicker-free based fixture with even, soft edge and pure color mixing coverage.

Features:

ABS die-cast plastic cover with Aluminum structure
Full pixel controllable
Color temperature Liner up and down in 2700-8000K
8/16 bit smooth and precise resolution for PAN/TILT movement
Auto preposition after unexpected movement
Fast, smooth and quiet motorized zoom with 6°-60° range
Even, soft edge and pure color mixing coverage
Flicker free sources management
Scan position memory, auto re-position after unexpected movement
0-100% Linear LED dimmer
7 Built-in default programs for easy operations
Variable speed strobe effect with 1-25 flashes per second
Variable pulse and random effects
2.4” TFT LCD display (320*240pix) with 4 control buttons
LCD display switch-off automatically after 1 second
180°Reversible for LCD display
POWERCON connector IN
3-Pin XLR connectors IN/OUT
Constant temperature readout and management function
2*1/4 turn fastening Omega Clamps(Adaptable vertically and horizontally)
1*Safety attachment point

Specifications:

Light Source
Lamp: 7x 10W 4-IN-1 RGBW LEDS
Life span: 50000 hours
Color: RGBW

Optics
Zoom angle: 6°-60°
Improved optics and flat beam field

Power Supply
Power supply: Battery or AC mains
Input Voltage:AC90-260V 50/60Hz
Power Consumption: Sate of charge 200W; non-charged state: 90W

Battery
Battery type: Lithium iron
Battery charge time:0% to 100% charge 5.5 hours,
Max-endurance:8 hours(Full power), 12 hours(built-in program)
Temperature detection function :(-20 ℃ to 45 ℃)
Battery protection: Battery short circuit protection, over current protection, overflow charging
Charging mode: When connected to mains and power is insufficient, battery will be charged automatically.
Support battery extension.

Control
Control Signal:DMX512, master-slave and sound activated ,auto operation or wireless
Sound control with sensitivity adjustment
Control Channel:15/13DMX channels USITT DMX-512
DMX recorder and function integrated

Movement
630° /540° /360° PAN and 270°/180° /90° TILT movement optional
Smooth and precise resolution for PAN/TILT movement
Scan position memory, auto preposition after unexpected movement.
PAN/TILT reversible advantage

Working Environment
-20°C-45°C max ambient temperature
Constant temperature readout and management function.
Protection Rating : IP 20

Construction & Weight
Dimensions:30.6*35.8*22.4(cm)
Packing Dimensions: 40X29X44.5(cm)
Net Weight:10.5kgs
Gross Weight: 12.5kgs
