Home
»
all
»
Brand JBL
»
Passive Speakers
»
JBL CSS-1S/T (Pair)
JBL CSS-1S/T (Pair)
$310.00
Order within [hour] to get by [date_end]
Default Title
Quantity
Quantity
Call For More Details
Call us at
123-456-7890
Add to cart
Delivery & Return
Returns & Exchanges Policy
All orders come with our industry leading
90-Day
return policy.
Cash Back or Store Credit available for returns within 30 days.
Store Credit available for returns within 31-90 days.
Restocking fees
Unopened Items: 5%
Opened but Mint Condition: 15%
Blemished, Missing/Damaged Packing or Accessories: 25%
Shipping Costs
Buyer is responsible for return shipping costs
If "Free" or discount shipping was provided with original order, our actual shipping cost will be deducted from the amount refunded/credited
Damages & Defects
We will swap any item reported as damaged or defective within 7 days of delivery for free. All transportation and replacement costs will be covered by us (within US48 states).
Guarantee Safe
Checkout
Description
Shipping
Return Policies
Versatile Compact Loudspeaker for Distributed Audio Systems
The
CSS-1S/T
is a compact and versatile two-way loudspeaker designed for both distributed 100V/70V speaker lines and 8 ohm direct mode applications. It features a 5.25-inch low-frequency driver and a 0.75-inch polycarbonate dome tweeter, providing high-quality sound reproduction for both music and speech. The speaker is designed to be purchased in pairs, ensuring balanced sound coverage for commercial or residential settings. An included wall-mounting bracket makes installation quick and easy.
CSS-1S/T Competitive Differences
Must be purchased in pairs for optimal stereo sound distribution.
Supports both 100V/70V distributed speaker lines and 8 ohm direct mode for flexible installation.
Includes a 10W multi-tap transformer with 10W, 5W, and 2.5W settings at 70V for distributed systems.
Designed with professional-grade drivers and crossover network for clear, full-range sound.
Wide 120ºH x 120ºV nominal coverage pattern for efficient sound distribution.
Wall-mounting bracket included for secure and easy installation.
CSS-1S/T Description
The
CSS-1S/T
loudspeaker is ideal for distributed audio systems where clear, full-range sound is required. Equipped with a 135mm (5.25 inch) low-frequency driver and a 19mm (0.75 inch) polycarbonate dome tweeter, this speaker offers excellent sound quality for both music and speech. It operates in either 100V or 70V distributed systems with a 10W multi-tap transformer and can be switched to 8 ohm direct mode for traditional speaker setups. The CSS-1S/T comes with a durable polypropylene enclosure and an included wall-mounting bracket, making it a versatile choice for various installations. Please note that these speakers are sold and must be purchased in pairs for proper sound performance.
CSS-1S/T Features
10W multi-tap transformer for 100V or 70V distributed systems
8 ohm direct setting for traditional speaker systems
135 mm (5.25 inch) low-frequency driver for rich bass response
19 mm (0.75 inch) polycarbonate dome tweeter for clear high frequencies
Wall-mounting bracket included for convenient installation
Professional drivers and network ensure optimal sound quality
Wide 120ºH x 120ºV nominal coverage pattern
CSS-1S/T Specifications
Frequency Range (-10dB): 85 Hz – 18 kHz
Frequency Response (±3 dB): 120 Hz – 16 kHz
Power Capacity: 60 Watts
Sensitivity: 86 dB SPL (1W, 2.83V at 1m)
Maximum SPL (1m): 106 dB in 8 Ohm Direct setting, 96 dB at 10W setting
Nominal Coverage: 120ºH x 120ºV
Directivity Factor (Q): 6.2
Directivity Index (DI): 7.9 dB
Nominal Impedance: 8 ohms (in 8Ω DIRECT mode, selectable)
Transformer Taps: 10W, 5W, 2.5W at 70V
Crossover Frequency: 4.3 kHz
LF Driver: 135 mm (5.25 inch) low-frequency driver
HF Driver: 19 mm (0.75 inch) polycarbonate dome tweeter
Input Connectors: Spring-loaded terminals
Enclosure Material: Polypropylene structural foam
Color: Black
Dimensions: 9.0 x 6.3 x 5.6 inches (229 x 159 x 143 mm)
Net Weight (each): 4.5 lbs (2.0 kg)
Shipping Weight (pair): 10.5 lbs (4.8 kg)
What's in the Box
(2) CSS-1S/T Loudspeakers
(2) Wall-mounting bracket assemblies
