Chauvet Pro Ovation Reve E-3 | Full-Spectrum LED Ellipsoidal | RGBA+Lime, 2800K–8000K Tunable

Ovation Rêve E-3

The Ovation Rêve E-3 is an incredibly bright, multi-color LED ellipsoidal that also offers perfectly tunable white light. This innovative LED light source combines the best of both worlds, creating a new standard in storytelling through lighting. It features color temperature presets from 2800K to 8000K, ensuring exceptional brightness and high-quality light, with an emulated “red shift” for a classic tungsten feel. The Ovation Rêve E-3 includes multiple dimming curves, operates virtually silently with fan-off modes, and boasts technician-friendly features like an adjustable yoke for easy mounting in low-clearance areas. With the Ovation Rêve E-3, you can effortlessly switch between vibrant, saturated colors and precise whites with +/- green adjustments using a single fixture. Simply put, it's categorically unrivalLED.

At a Glance

• Full-spectrum LED ERS-style lighting fixture for theatre, film, and production
• Linear color temperature presets from 2800K to 8000K with high CRI and CQS
• Virtual color wheel with colors matched to popular gels
• +/- Green adjustment and emulated red-shift via DMX or onboard control
• RDM (Remote Device Management) for increased flexibility
• Adjustable PWM (Pulse Width Modulation) to prevent flickering on camera
• Virtually silent operation for use in studios, film, and theatre applications
• Ultra-smooth 18-bit dimming curves and speeds to enhance any lighting setup
• Innovative adjustable yoke for mounting in low-clearance areas
• Direct power/data connection and control options for the Ovation GR-1 gobo rotator
• USB port for fixture software updates

Specifications

Optical

• Light Source: 91 LEDs (12 red, 19 green, 3 blue, 9 royal blue, 24 amber, 24 mint) 3.5 to 10 W, (2.4 A), 50,000 hours life expectancy (L70)
• Color Temperature (range): 2800 to 8000 K
• Color Temperature (at full): 5470K
• CRI (3200 K): 95.4
• Beam Angle (w/5° lens): 4.6°
• Beam Angle (w/10° lens): 10°
• Beam Angle (w/14° lens): 14.8°
• Beam Angle (w/19° lens): 18.5°
• Beam Angle (w/26° lens): 26°
• Beam Angle (w/36° lens): 33.3°
• Beam Angle (w/50° lens): 49.5°
• Beam Angle (w/15°–30° lens)(Narrow): 13°
• Beam Angle (w/15°–30° lens)(Wide): 28.5°
• Beam Angle (w/25°–50° lens)(Narrow): 23.6°
• Beam Angle (w/25°–50° lens)(Wide): 40.5°
• Field Angle (w/5° lens): 5.6°
• Field Angle (w/10° lens): 11.1°
• Field Angle (w/14° lens): 16°
• Field Angle (w/19° lens): 21.6°
• Field Angle (w/26° lens): 29.6°
• Field Angle (w/36° lens): 37.1°
• Field Angle (w/50° lens): 55.7°
• Field Angle (w/15°–30° lens)(Narrow): 15.4°
• Field Angle (w/15°–30° lens)(Wide): 32.2°
• Field Angle (w/25°–50° lens)(Narrow): 25.8°
• Field Angle (w/25°–50° lens)(Wide): 44.1°
• Lumens (w/5° lens): 5,076
• Lumens (w/10° lens): 11,250
• Lumens (w/14° lens): 12,179
• Lumens (w/19° lens): 12,156
• Lumens (w/26° lens): 13,300
• Lumens (w/36° lens): 13,223
• Lumens (w/50° lens): 12,216
• Lumens (w/15°–30° lens): 12,057
• Lumens (w/25°–50° lens): 14,355
• Illuminance (w/5° lens): 31,856 lux @ 5 m
• Illuminance (w/10° lens): 18,924 lux @ 5 m
• Illuminance (w/14° lens): 9,284 lux @ 5 m
• Illuminance (w/19° lens): 5,635 lux @ 5 m
• Illuminance (w/26° lens): 3,378 lux @ 5 m
• Illuminance (w/36° lens): 2,085 lux @ 5 m
• Illuminance (w/50° lens): 870 lux @ 5 m
• Illuminance (w/15°–30° lens)(Narrow): 9,292 lux @ 5 m
• Illuminance (w/15°–30° lens)(Wide): 2,671 lux @ 5 m
• Illuminance (w/25°–50° lens)(Narrow): 3,710 lux @ 5 m
• Illuminance (w/25°–50° lens)(Wide): 1,527 lux @ 5 m
• Barrel Rotation: +/- 25°
• Selectable PWM: 600 Hz, 1,200 Hz, 2,000 Hz, 4,000 Hz, 6,000 Hz, 25,000 Hz

Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Focus: Manual
• Strobe Rate: 0 to 30 Hz
• Standalone Color Mixing: Yes
• Color Temperature Presets: Yes
• Dim Modes: 4
• Dim Curves: 4
• Built-in Automated Programs: Yes

Construction / Physical

• Dimensions (fixture only, yoke up): 20.44 x 13.07 x 20.53 in (519 x 332 x 522 mm)
• Dimensions (w/5° lens extended, yoke up): 41.60 x 14.17 x 21.42 in (1056 x 360 x 544 mm)
• Dimensions (w/10° lens extended, yoke up): 32.87 x 13.07 x 20.01 in (835 x 332 x 510 mm)
• Dimensions (w/14° lens extended, yoke up): 29.7 x 13.07 x 20.53 in (755 x 332 x 522 mm)
• Dimensions (w/19°, 26°, 36° or 50° lens extended, yoke up): 26.83 x 13.07 x 20.53 in (681 x 332 x 522 mm)
• Dimensions (w/15°–30° lens, yoke up): 33.02 x 13.52 x 20.53 in (839 x 343 x 522 mm)
• Dimensions (w/25°
