Chauvet DJ COREpar Q120 ILS

Mobile entertainers and lighting technicians in need of a wash light will be impressed with the CHAUVET DJ COREpar Q120 ILS, a low-profile LED PAR that's powered by a 120W quad-color COB LED (red, green, blue, white) and lets you generate a broad spectrum of colors, well suited for clubs, bars, concerts, special events, parties, and more. The Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced, coordinated light show across multiple fixture types, allowing any ILS-enabled fixture to be controlled wired or wirelessly. The COREpar Q120 ILS allows you to create custom colors using the built-in LED display and achieve smooth LED fading with built-in dimming curves. The fixture is flicker free, making a great choice for on-camera work. The fixture is equipped with a universal, auto-sensing power supply and is compatible with the IRC-6 wireless remote (available separately) and D-Fi USB (available separately) for wireless primary/secondary and DMX applications.

COB (Chip-on-Board) LED produces a full spectrum of light with unsurpassed color mixing
Integrated Lighting System (ILS) is a complete lighting ecosystem technology that provides an advanced, coordinated light show across multiple fixture types
D-Fi USB compatibility for wireless primary/secondary or DMX control
Included magnetic Fresnel lens allows flexibility to go from an ultrawide to a narrow beam in seconds
Withstand the harshness of traveling from gig to gig with a robust housing
Sit-flat housing design hugs the floor and features power and DMX outlets on the side of the unit
Achieve flicker-free video operation with high-frequency LED dimming
Save time running cables and extension cords by power linking multiple units
Point-and-shoot operation of static colors and automated programs with the optional IRC-6 remote
Create customized colors using the built-in LED display
Achieve smooth LED fading with built-in dimming curves
Easily transports in the optional CHS-40 VIP Gear Bag

FEATURES:

Integrated Lighting System (ILS)
Generate a Broad Spectrum of Colors
Natural Color Temperatures
Static Color Mixing
DMX and Power Linking Capable
D-Fi USB Compatibility for Wireless DMX
Compatible with Optional IRC-6 Remote
Flicker-Free Operation for Cameras
DMX + Built-In Dimming Curves
Includes Power Cord

SPECIFICATIONS:

Light Type PAR
Light Source 1 x Color LED (COB) - 120 W / 6.9 A
Light Source Life Expectancy 50,000 Hours
Colors Red
Green
Blue
White
Photometrics 80.6 fc / 868 Lux at 6.6' / 2 m
431 fc / 4639 Lux at 78.7" / 2 m
Color Temperature 2700 to 6000K
Beam Angle 56°
20° (with Installed Lens)
Field Angle 100°
30° (with Installed Lens)
Shutter / Strobe Electronic
Dimming Electronic, 0 to 100%
Performance
Operating Modes DMX, Primary/Secondary, Sound-Active
Macros / Programs None
Effects Strobe
Strobe Rate 0 to 29 Hz
Gobos None
Control
Control Protocols DMX512
DMX Channel Modes 2 Mode(s):
4 / 9-Channel
Remote Control D-Fi USB, IR Remote (with Optional Equipment)
App Compatible No
Connectivity
Inputs/Outputs 1 x XLR 3-Pin DMX Input
1 x XLR 3-Pin DMX Output
1 x USB Type-A Remote Input
Power
AC Input Power 100 to 240 VAC, 50/60 Hz
AC Power Connector Input: 1 x IEC
Output: 1 x Edison
Power / Current Consumption 120 VAC: 100 W / 1.3 A
230 VAC: 94 W / 0.7 A
Power Linking 6 Units at 120 VAC
10 Units at 230 VAC
Environmental
IP Rating None
Physical
Mounting Dual/Scissor Yoke
Included Accessories 1 x Power Cable
Duty Cycle None
Exterior Color Black
Max Housing Temperature 219°F / 104°C
Cooling Convection
Certifications CE, RoHS,
*as per Manufacturer
Dimensions 9 x 8.9 x 7.4" / 22.8 x 22.5 x 18.8 cm
Weight 4.6 lb / 2.1 kg
