Ashly CA 1.04 | 4-Channel 1000W Ultra-Efficient Installation Amplifier

High-Efficiency 4-Channel Power Amplifier for Installations

The Ashly CA-1.04 is a powerful and ultra-efficient 4-channel amplifier designed for professional installations. With its advanced D-MAX Class D design, Dynamic Power Factor Correction (DPFC), and flexible connectivity options, the CA-1.04 delivers up to 1000W per channel and supports both low-impedance (2, 4, and 8 ohms) and high-impedance (70V/100V) configurations. Ideal for venues requiring reliable and scalable sound reinforcement, the CA-1.04 combines power, efficiency, and installer-friendly features.

Ashly CA-1.04 Competitive Differences

• Four channels delivering 1000W per channel at 4 ohms or 70V
• D-MAX Class D amplification for exceptional efficiency and performance
• Dynamic Power Factor Correction (DPFC) ensures consistent power delivery
• Switchable high-pass filters (HPF) and clip limiters for each channel
• Adjustable front-panel input gain with lock-out for precise control
• Bi-lateral SailFlow cooling system for optimized thermal management
• Installer-friendly Euroblock and XLR combo connectors
• Supports 100V operation in bridged mode with 2000W output

Ashly CA-1.04 Description

The Ashly CA-1.04 represents the pinnacle of amplifier efficiency and versatility. Equipped with Ashly’s D-MAX Class D technology, it delivers up to 1000W per channel at 4 ohms or 70V, making it perfect for both low-impedance and high-impedance sound systems. The inclusion of Dynamic Power Factor Correction ensures consistent power output while minimizing energy consumption. The CA-1.04 offers extensive control options, including per-channel high-pass filters, clip limiters, and adjustable input gain. Its bi-lateral SailFlow cooling system efficiently directs airflow to prevent overheating, ensuring reliable performance even under demanding conditions. With its rugged construction and installer-friendly connectors, the CA-1.04 is an ideal solution for large-scale venues, houses of worship, and corporate installations.

CA-1.04 Features

• 4 channels, each delivering:
  • 1000W @ 2 ohms or 4 ohms
  • 500W @ 8 ohms
  • 1000W @ 70V constant voltage
• 2000W bridged @ 8 ohms or 100V constant voltage
• D-MAX Class D amplification with Dynamic Power Factor Correction (DPFC)
• Per-channel adjustable input gain with lock-out
• Switchable high-pass filters (HPF) and clip limiters per channel
• Euroblock and XLR combo input connectors
• Bi-lateral SailFlow cooling architecture
• Rugged metal front panel with clear LED indicators

CA-1.04 Specifications

• Number of Channels: 4
• Power Output:
  • 1000W per channel @ 2/4 ohms or 70V
  • 500W per channel @ 8 ohms
  • 2000W bridged @ 100V or 8 ohms
• Amplifier Class: Class-D
• Cooling: Bi-lateral SailFlow cooling system
• Input Connections: Euroblock and XLR combo connectors
• Operating Voltage: Supports 70V and 100V constant voltage systems
