American DJ Jolt Panel FX2 | RGB & Cool White Strobe, Wash & Eye-Candy Effects

$879.99

Order within [hour] to get by [date_end]

Quantity

Pickup available at NJ Warehouse.

Usually ready in 1 hour

American DJ Jolt Panel FX2 | RGB & Cool White Strobe, Wash & Eye-Candy Effects

NJ Warehouse

Pickup available, usually ready in 1 hour

238 U.S. 206
Byram Township NJ 07821
United States

Guarantee Safe
Checkout

trust_2dea69ed-7223-44f3-828d-a80bc0f3aef4

High-Performance RGB Strobe and Wash Panel

The American DJ Jolt Panel FX2 is a powerful and versatile lighting fixture designed for concert productions, festival stages, rental houses, and nightclub installations. With its strikingly bright white strobe, vibrant color washes, and animated eye-candy chase effects, this fixture delivers dynamic visual impact. Featuring 800 RGB SMD LEDs and 48 high-power cool white LEDs, it provides high-output performance with multiple control options, making it a must-have for professional lighting designers.

American DJ Jolt Panel FX2 Competitive Differences

Dual-purpose LED panel with both high-intensity white strobe and vibrant RGB color washes.
40 RGB LED zones and 6 Cool White LED zones for detailed pixel mapping effects.
67 built-in color temperature presets (2300K-8900K) for customizable lighting.
Integrated Aria X2 Management Suite for advanced lighting control.
Selectable LED refresh rates from 900Hz to 25kHz for flicker-free operation.
Four selectable dimming curves for smooth fades and transitions.
IP65-rated locking 5-pin DMX and power connections for reliability in demanding environments.
Includes a frost lens filter for softening pixel dots and achieving different lighting effects.

American DJ Jolt Panel FX2 Description

The American DJ Jolt Panel FX2 is built to provide lighting designers with unlimited creative possibilities. It features a combination of 800 x 0.5W RGB SMD LEDs and 48 x 5W cool white SMD LEDs, allowing it to function as a high-output strobe, a dynamic color wash, or an animated pixel-effect panel. With 40 independent RGB LED zones and 6 cool white LED zones, users can create stunning visual effects with precise control. Designed for versatility, the Jolt Panel FX2 includes 25 built-in RGB LED macros and 9 cool white LED macros, making it easy to generate striking effects on the fly. The fixture also offers 14 DMX channel modes and supports multiple control protocols, including DMX, Aria X2, and RDM. Ideal for professional applications, the Jolt Panel FX2 features a rugged design with IP65-rated locking power and DMX connections, ensuring reliability in live event settings. With a selectable LED refresh rate (900Hz-25kHz) and multiple dimming modes, it provides smooth and flicker-free operation for broadcast, stage, and club environments.

Jolt Panel FX2 Features

800 x 0.5W RGB SMD LEDs + 48 x 5W cool white SMD LEDs.
73° beam angle and 111° field angle for wide coverage.
40 RGB LED zones and 6 cool white LED zones for dynamic effects.
67 built-in color temperature presets ranging from 2300K to 8900K.
25 built-in RGB LED program macros and 9 cool white LED macros.
Integrated Aria X2 Management Suite for advanced control.
0-100% smooth dimming with 6 dimming presets.
4 selectable dimming curves (Linear, Square Law, Inv Square Law, S Curve).
Strobe effects: Ramp Up/Down, Lightning, Random (1Hz to 20Hz).
Selectable LED refresh rate from 900Hz to 25kHz for flicker-free operation.
Includes frost lens filter for softening light output.

Jolt Panel FX2 Control

DMX, Aria X2, and RDM control protocols.
14 DMX channel modes: 6, 9, 13, 18, 20, 36, 41, 43, 51, 81, 83, 126, 141, and 143 channels.
OLED display with 4-button touch menu for easy navigation.

Jolt Panel FX2 Connections

IP65-rated locking 5-pin DMX In/Out for data connection.
IP65-rated locking power In/Out for daisy-chaining multiple units.

Jolt Panel FX2 Electrical

Auto-sensing power supply: 100-240V, 50/60Hz.
Maximum power consumption: 214W at 120V / 208W at 230V.
Maximum power link: 6 units at 120V, 12 units at 230V.
Fuse protected: T5A/250V glass fuse (5x20mm).

Jolt Panel FX2 Dimensions & Weight

Length: 5.28" (134.2mm).
Width: 16.42” (417mm).
Height: 10.26” (260.5mm).
Weight: 13.67 lbs (6.2 kg).

What’s Included

1 x IP65 Locking Power Cable.
1 x Frost Lens Filter.
